C2 is a revolutionary high-performance screw designed using modern manufacturing methods. Its superior holding strength in a wide variety of materials provides ultimate performance.
• Deep recess to prevent 'cam-out', giving a precise and positive drive control on every screw
• Ribs under head for improved countersinking and to give a smooth and flush finish, also prevents splitting and material damage
• Coated with a high-molecular polymer lubricant that reduces the insertion torque by up to 52% and increases rust protection up to 20 times longer than a standard zinc plating
• Dual angle thread for ultimate performance and exceptionally high pull-out resistance
• All sizes up to and including 75mm are fully threaded and lengths 80mm and above all have 70mm thread length
Product Specifications
| Application |
Joinery, Carpentry, Timber Construction, Furniture Manufacturing |
| Carton Qty (packs) |
140 |
| Corrosion Rating (1-5) |
2 - Occasionally damp/wet, rural and sheltered areas |
| Driver Bit Size |
PZ2 |
| Finish |
Zinc & Yellow |
| Gauge |
6 |
| Head Ø (mm) |
6.6 |
| Head Type |
Double Countersunk |
| Indoor/Outdoor Usage |
Indoor, Covered Outdoor |
| L (inch) |
5⁄8 |
| L (mm) |
16 |
| Lubrication |
Gleitmo |
| Material |
Hardened Steel |
| MOQ |
1 |
| MOQ Increment |
1 |
| Pack Dimensions L x W x H (mm) |
54 x 42 x 34 |
| Pack Qty |
200 |
| Pack Quantity Unit |
Pieces |
| Pack Type |
Box |
| Pack Weight (kg) |
0.16 |
| Point Type |
Sharp |
| Recess Type |
Pozi |
| Resistant Type |
Corrosion-Resistant |
| Size |
3.5 x 16 |
| Size (imp.) |
6 x 5⁄8 |
| Size (mm) |
3.5 x 16 |
| Substrates |
Hardwood, Softwood, Chipboard, MDF, Plastic, Thin Sheet Metal |
| Thread L (mm) |
11 |
| Thread Ø (mm) |
3.5 |
| Thread Type |
40° Single |
